> For the complete documentation index, see [llms.txt](https://docs.zmanda.com/llms.txt). Markdown versions of documentation pages are available by appending `.md` to page URLs; this page is available as [Markdown](https://docs.zmanda.com/zmanda-classic/installation-and-configuration/step-1-install-zmanda-server/linux-binary-installation.md). # Linux Binary Installation {% hint style="info" %} If you already have one backup server and Zmanda Management Console configured and are wanting to build another backup server for clustering purposes, you may skip the installation steps pertaining to the ZMC and only need to download and install the binaries for the Zmanda Backup Server. {% endhint %} ### Installation Steps ### **Step 1: Preparing the Linux system for Zmanda Installation** **1.1 Update the target Linux system** by running one of the following commands, based on the Linux distribution. For RPM-based systems, use dnf or yum: ``` sudo dnf update -y ``` For Debian-based systems. ``` sudo apt-get update -y ``` **1.2.1** **Install the dependencies required by Zmanda** by running one of the two commands shown below, based on the Linux distribution (yum for RPM and apt-get for Debian) For RPM-based systems, use dnf or yum: ``` sudo dnf install -y wget xinetd vim samba samba-common samba-client mtx lsscsi mt-st bind-utils libnsl ``` For Debian-based systems: ``` sudo apt-get install -y wget xinetd vim samba samba-common samba-client mtx lsscsi mt-st bind9 bind9utils bind9-doc dnsutils libnsl libnsl2 ``` * **wget** to aid file download via CDN links * **xinetd** to manage internet-based connectivity * **samba, samba-common,** and **samba- client** for CIFS backups * **mt-st, mt, & mtx** for tape storage * **mlocate** is a useful tool for finding specific files * **bind-utils** for DNS utilities (might be missing on some distributions) * **libnsl** nsi libary (might be missing on some distributions) **1.2.2 OPTIONALLY Install the dependencies needed to back up VMware Sources.** For more information, [see this article. ](https://kb.zmanda.com/how-to-install-the-zmanda-vmware-dependencies) **1.3** Depending on the Linux distribution, SELinux may come pre-enabled. For installations or reboots, if your system has SELinux enabled and set to enforcing mode, **please change it to Permissive mode**. Check the SELinux mode by running **getenforce** command. ``` >getenforce Enforcing ``` If the mode is set to Enforcing, execute the following commands to change it to Permissive mode: ``` sudo setenforce 0 sudo sed -i 's/SELINUX=enforcing/SELINUX=permissive/g' /etc/selinux/config ``` ### **Step 2: Zmanda Installation:** **2.1 Login to** [**Network.Zmanda.com**](https://network.zmanda.com) from a browser of your choice and select **Download** from the left side navigation bar. If you don't already have an account, [**Register Here**](https://network.zmanda.com/register). **2.2 Navigate to the Backup Server** label in the **Enterprise Server** section and select your Linux distribution from the dropdown. The corresponding backup server *and* ZMC binaries will appear to the right of the drop-down once you select a distribution. *You need to download both binaries.*

Backup server binaries

**2.3 A wget of the CDN link can be used to download the Zmanda installation binaries** onto your target Linux system. Find the CDN links by clicking on the download icons for both the backup server and ZMC (shown above) and then by navigating to the downloads page in your browser where you can copy the link address and paste it into your SSH terminal. For most browsers, Ctrl-J will take you to the downloads page. ``` wget wget ``` **2.4 Make both files executable by running the following commands.** ``` // offering the installer execute permissions chmod +x zmanda-backup-server-.run chmod +x zmanda-zmc-.run ``` **2.5 Install Zmanda by first executing the backup server binaries, and then by executing the ZMC binaries as shown below. The order is important.** Both installations will give you a few simple prompts, so be sure to answer those when they appear. You may run into a few more missing libraries during the installation of these binaries, depending on your Linux system. Please install the necessary libraries and retry the installer. ``` // running the backup server installation sudo ./zmanda-backup-server-.run // running the ZMC UI binary sudo ./zmanda-zmc-.run ``` **2.6 Verify the Zmanda installation and Apply Patches** Enter the command **setup-aee** to verify that all the backup server packages are installed and all the units are running. Enter the command **setup-zmc** to verify that all the zmc packages are installed and all the units are running. **Note:** For both commands, you may see the text **install-disabled tools: \.** The absence of these packages need not halt your installation - they may be installed later and are used for specific use cases. As long as you see that all the packages are installed and units are running, you will be ready to move on to the next step.
{% hint style="info" %} Setting the **Unsealed** parameter shown above to "true" is essential. If it is set to "false", run the following command, then run **setup-zmc** again to ensure that the vault is unsealed. {% endhint %} ``` sudo setup-zmc unseal ``` {% hint style="warning" %} Please keep a safe copy of the unseal keys, as losing them will make Zmanda unusable. Refer [here](https://kb.zmanda.com/key-vault-unseal-keys) for more information on how to create a secure copy of unseal keys and unseal the key vault. {% endhint %} Go to **network.zmanda.com** and download any patches that are available (see below). Untar them and find and execute the patch executable.
For assistance or questions, please email **2.7 Set the password that you will use to login** to the web-based Zmanda Management Console Enter the following command. Enter **admin** as the username and enter a secure password. Please note the length and complexity requirements. ``` sudo /opt/zmanda/amanda/bin/reset-admin-password //Length and Complexity Requirements length should be at least 8 Password should have at least one numeral Password should have at least one uppercase letter Password should have at least one of the symbols $,@,#,%,^,&,*,~ ``` \*\*2.8 Zmanda requires specific ports to be open (\*\*see below). For more information, and for commands to configure firewall rules, please see [this KB Article](https://kb.zmanda.com/network-ports-amanda-enterprise). * 10080:10081 * 8002 * 8008 * 800:840 Run the following command to open these ports. (ufw may not be installed depending on the Linux distribution. If not, see the next steps below) ``` sudo ufw allow 8008,8002,10080,10081,800:840 ``` If your system does not have ufw installed (i.e. RHEL where adding UFW and EPEL is not an option), follow the instructions below. Execute the first command to see if the firewall is running. If the firewall is not running, you can skip the other two commands. ``` sudo firewall-cmd --state sudo firewall-cmd --zone=public --add-port=10080-10081/tcp --permanent sudo firewall-cmd --zone=public --add-port=800-840/tcp --permanent sudo firewall-cmd --zone=public --add-port=8008/tcp --permanent sudo firewall-cmd --zone=public --add-port=8002/tcp --permanent sudo firewall-cmd --reload ``` ### **Step 3: Zmanda License Installation and Server Configuration:** **3.1 Note the MAC address and ip-address of the server** Execute "**ip addr**" command from the shell of the Linux server and note down the mac address and IP address. See the picture below. The red box shows where you can find the mac address and the blue box shows where you can find the IP address. ``` ip addr ```
**3.2 Download the license from Network.Zmanda.com** Login to Network.Zmanda.com and go to the license section. Click the![](/files/FrKkS1RghfTsvGfQuJEk)button next to the license and it will prompt you for the MAC address and a server name. Enter the MAC address you noted down above and a server name. The server name is not validated and is for your convenience only. Click **SUBMIT**.
Upon clicking submit, you will be prompted to copy the One Time PassKey which will be valid for 30 minutes. You should copy this key and paste it into a text editor or other safe place. You will need it when you upload the license to the ZMC. Once copied/saved, select **CLICK TO BEGIN DOWNLOAD**
With the license file downloaded, please ensure the file name is **zmanda\_license** with no other text appended. {% hint style="info" %} If you do not see the One Time PassKey box as shown above, you are either downloading a trial license, or a license for a previous version of Zmanda. If the version looks correct and you are expecting a Production License, please email If you are expecting a Trial License, you may still see the pop-up, so proceed to copy the key. {% endhint %} **3.3 Install license in Zmanda Management Console** From a browser of your choice, enter **http\://\:8008**. Enter the credentials to log in. The username will be admin, and the password will be the password that you reset during the installation steps above. Go to Settings -> Licenses and click **Upload File**. Select the license file, enter the passkey that you copied, and click **Upload**.
{% hint style="info" %} Make sure to check the **I have a free Trial License** box *if you were NOT* given a PassKey as shown in step 3.2. {% endhint %} **3.4 Configure the backup server in ZMC** Go to Settings -> Cluster page. Click **Add Server** and enter the server name, server region, IP address, and port. Enter a backup server name and region. Again, these are for your reference purposes only. Enter the IP of the backup server, in this case, it is the IP address of the same system, noted down from **ip addr** command. The default port is 8002. Click save to complete the addition of the backup server. ### Conclusion Congratulations! By following these steps, you have successfully performed a binary-based installation of Zmanda and logged in for the first time. You will now be able to go through a guided tour of the console and take the next steps to protect your valuable data. --- # Agent Instructions This documentation is published with GitBook. GitBook is the documentation platform designed so that both humans and AI agents can read, navigate, and reason over technical content effectively. Learn more at gitbook.com. ## Querying This Documentation If you need additional information that is not directly available in this page, you can query the documentation dynamically by asking a question. Perform an HTTP GET request on the current page URL with the `ask` query parameter, and the optional `goal` query parameter: ``` GET https://docs.zmanda.com/zmanda-classic/installation-and-configuration/step-1-install-zmanda-server/linux-binary-installation.md?ask=&goal= ``` `ask` is the immediate question: it should be specific, self-contained, and written in natural language. `goal` is optional and describes the broader end goal you are ultimately trying to accomplish on behalf of the user. GitBook uses it to tailor the answer towards what is most useful for that goal. The response will contain a direct answer to the question and relevant excerpts and sources from the documentation. Use this mechanism when the answer is not explicitly present in the current page, you need clarification or additional context, or you want to retrieve related documentation sections.
